VIVOTEK AW-GEV-104B-130 Switch L2 man. 10-Port PoE

VIVOTEK AW-GEV-104B-130 Switch L2 man. 10-Port PoE

SKU: EX-10036505

GTIN: 4712123676555

Category: Switches

Delivery time: ca. 4 weeks (DE - int. shipments may differ)

532,45 €

incl. 19% VAT ,

Manufacturers: Vivotek

Switch | PoE-Stromversorgung | Anwendung: Videoüberwachung | Farbe: Schwarz

piece

Description

BESCHREIBUNG

VIVOTEK AW-GEV-104B-130 Switch L2 Smart managed 10-Port, PoE

Produktbesonderheiten:

DHCP-Server &amp. Client &amp. Relay &amp. Snooping
Tag-basiertes VLAN, Port-basiertes VLAN, Protokoll-basiertes VLAN, IP-Subnetz-basiertes VLAN, MAC-basiertes VLAN
Privates VLAN Edge (PVE), Sprach-VLAN, Q-in-Q-VLAN, GARP-VLAN
Multicast-VLAN-Registrierung (MVR)
802.1d (STP), 802.1w (RSTP) und 802.1s (MSTP) und Schleifenschutz
LACP IEEE 802.3ad und Static Link Aggregation
IGMP Snooping v1/v2/v3 &amp. Querer &amp. Proxy
Basierend auf IEEE 802.1X RADIUS-Authentifizierung und IGMP-RADIUS
SNMP v1/v2c/v3 Benutzerbasiertes Sicherheitsmodell (USM)
IEEE802.3az Energieeffizientes Ethernet
Automatisches Lernen und automatische Alterung der MAC-Adresse

Passende SFP-Module:

SFP-1000-MM85-X5 1.25G, MMF, 0.5km
SFP-1000-MM13-02 1.25G, MMF, 2km
SFP-1000-SM13-10 1.25G, SMF, 10km
SFP-1000-SM13-40 1.25G, SMF, 40km
SFP-1000-CPTX-X1 1G SFP to RJ45

EIGENSCHAFTEN

Produktart

Typ: Switch
Einsatzbereich: Innenbereich
Farbe: Schwarz
Funktionen: PoE-Stromversorgung
Anwendung: Videoüberwachung

Ausstattung

Besonderheiten: mit PoE-Switch (Stromversorgung für Kameras) NDAA (National Defense Authorization Act) Google Map View Topology View Floor View Auto Discovery Live Streaming Device Management Device Status VLAN Setting VivoCam L2 Managed
Anschlüsse: RJ-45 (LAN) RJ-45 PoE (LAN) 100 - 240 V AC SFP 2x SFP Port 100M/1G 8x RJ45 Port 10M/100M/1G

Sonstiges

Tiefe: 242 mm
Gewicht: 1,95 kg
Höhe: 44 mm
Breite: 220 mm

Stromversorgung

Spannungsversorgung: 100 - 240 V AC

TECHNISCHE DATEN

Model: AW-GEV-104B-130
Product Description
8xGE PoE + 2xGE SFP
VivoCam Web
Smart Managed PoE Switch
Port Configuration
10M/100M/1G RJ45 Port: 8
100M/1G SFP Port: 2
Total Ports: 10
Auto MDI/MDI-X: V
IEEE 802.3x: V
IEEE 802.3u: V
IEEE 802.3z: V
IEEE 802.3ab: V
HW Performance
Switching Bandwidth 20Gbps 36Gbps 52Gbps
Buffer Memory 4.1Mb 4.1Mb 4.1Mb
MAC Address 8K 8K 8K
Jumbo Frames 10000 Bytes 10000 Bytes 10000 Bytes
Managing IP Surveillance Functions
Management
Auto Search VIVOTEK Device: up to 256 pcs
Surveillance Device Management List: V
DHCP Server Function: V
VIVOTEK Device Account/Password Setting: V
VIVOTEK Device Static IP Setting: V
VIVOTEK Device Grouping Setting for VLAN: V
VIVOTEK Device Name Edit: V
VIVOTEK Camera/Video Server Reboot/Restore Default
V
VIVOTEK Device Re-direct Link: V
VIVOTEK Device On/Off Line Status: V V V
E-Map View
Topology View: V
Floor View: V
Google Map View: V
Maintenance
VIVOTEK Camera/Video Server Configuration File
Export/Import: V
VIVOTEK Cameras/Video Server Configuration File
Management: V
Floor Image Management: V
Export Surveillance Management Device List: V
Security: V
Trouble Shooting: V
Traffic Monitoring: V
Web Smart Managed Functions
Spanning Tree
IEEE802.1D (STP): V
IEEE802.1w (RSTP): V
IEEE802.1s (MSTP): V
IEEE802.1d (LACP): V
Trunking
Static Aggregation: V
VLAN
802.1Q Tag-based VLAN: 4096 VLAN IDs
Port-based VLAN: V
Private VLAN Edge (PVE): V
GARP VLAN: V
Q-in-Q (Double Tag): V
Protocol-based VLAN: V
MAC-based VLAN: V
Voice VLAN: V
IP Subnet-based VLAN: V
Multicast VLAN Registration (MVR)
V
IGMP Snooping (v1/v2/v3): V
DHCP Relay: V
MLD v1/v2 Snooping: V
QoS Functions
Hardware Queues: 8
Classification
Port Based: V
802.1p: V
Rate Limiting
Ingress: V
Egress: V
Per Port: V
Priority Queue Scheduling
WRR: V
DSCP &amp. Class of Service: V
Security
IEEE802.1x
RADIUS Authntication: V
IGMP-RADIUS Based: V
Secure Sockets Layer (SSL): V
Port Security: V
IP Source Guard: V
Storm Control: V
Layer 2 Isolation Private VLAN Edge (PVE): V
RADIUS/TACACS+: V
Loop Detection: V
DHCP Snooping: V
Management
SNMP (v1, v2c, v3): V
RMON (1,2,3 &amp. 9 groups): V
DHCP Server &amp. Client: V
Port Mirroring: V
UPnP: V
LLDP (IEEE802.1ab): V
LLDP-MED: V
S-Flow: V
Firmware Upgrade: V
NTP: V
TFTP: V
PoE Management
PoE On/Off Control: V
PoE Alive Checking for PD: V
PoE Scheduling: V
Power Delay: V
PoE Functions
IEEE 802.3af/at PoE Standard Compliant: V
Number of PoE Output Port: 8
PoE output Power: Per Port 54VDC, Max. 30W
Totoal PoE Power Budget: 130W
PoE Pin Assignment: 1/2(+), 3/6(-)
Surge Protection: Per PoE Port 6KV
Environmental Specifications
Operating Temperature: 0°C ~ 50°C (32°F ~ 122°F)
Storage Temperature: -20°C ~ 70°C (-4°F ~ 158°F)
Operating Humidity: 10 ~ 90% RH
Mechanical Specifications
Dimensions: 220 (W) x 44 (H) x 242 (D) mm
Weight: 1.95 kg
Power Source
AC Input: 100V ~ 240V
Frequency: 50 ~ 60 Hz
Power Consumption: 150W
Certifications
Certifications: FCC, LVD, VCCI, C-Tick
Accessories
Included Accessories: Power Cord, QIG, CD,
Manual, Rack Mount Kit

LIEFERUMFANG

1x VIVOTEK AW-GEV-104B-130 Switch L2 Smart managed 10-Port, PoE

Angaben gemäß EU-Verordnung (EU) 2023/988 (GPSR):
VIVOTEK INC.
6F, No.192, Lien-Cheng Rd, Chung-Ho, 23553 New Taipei City, Taiwan
Webadresse: www.vivotek.com
