VIVOTEK AW-GEV-267A-370 Switch L2 man. 26-Port PoE

Artikelnummer: EX-10036507

Kategorie: PoE

Lieferzeit: 10 Werktage DE

1.055,31 €

inkl. 19% USt. ,

VIVOTEK AW-GEV-267A-370 Switch L2 man. 26-Port PoE Switch PoE-Stromversorgung Anwendung: Videoüberwachung Farbe: Schwarz

Stk

Komponenten werden geladen ...

Beschreibung

VIVOTEK AW-GEV-267A-370 Switch L2 man. 26-Port PoE Switch PoE-Stromversorgung Anwendung: Videoüberwachung Farbe: Schwarz

Model: AW-GEV-267A-370
Product Description: VivoCam L2+ Managed PoE Switch 24xGE PoE + 2xGE Combo + 1xRJ45 Console

Managing IP Surveillance Functions

Management:

Auto Search VIVOTEK Device: up to 1000 pcs
Surveillance Device Management List: V
DHCP Server Function: V
VIVOTEK Device Account/Password Setting: V
VIVOTEK Device Static IP Setting: V
VIVOTEK Device Grouping Setting for VLAN: V
VIVOTEK Device Name Edit: V
VIVOTEK Camera/Video Server Reboot/Restore Default: V
VIVOTEK Device Re-direct Link: V
VIVOTEK Device On/Off Line Status: V

Graphic View:

Topology View: V
Floor View: V
Google Map View: V

Maintenance:

VIVOTEK Camera/Video Server Configuration File Export/Import: V
VIVOTEK Cameras/Video Server Configuration File Management: V
Floor Image Management: V
Export Surveillance Management Device List: V
Security: V
Trouble Shooting: V
Traffic Monitoring: V

Managed Layer 2+ PoE Switch Functions

Port Configuration:

10M/100M/1G RJ45 PoE Port: 24
GE RJ45/SFP Combo Port: 2
RJ45 Console Port: 1
Total Ports: 27
Auto MDI/MDI-X: V
IEEE 802.3x: V
IEEE 802.3u: V
IEEE 802.3z: V
IEEE 802.3ab: V

HW Performance:

Switching Bandwidth: 52Gbps
Forwarding Capacity: 38.68 Mpps
MAC Address: 8K
Jumbo Frames: 9600 Bytes
Surge Protection: Per Port 6KV

Layer 2+ Features

Spanning Tree

IEEE802.1D (STP): V
IEEE802.1w (RSTP): V
IEEE802.1s (MSTP): V

VLAN:

802.1Q VLAN: 4096 VLAN IDs
SVL/ IVL: V
Private VLAN: V
Guest VLAN: V
Q-in-Q (Double Tag): V
802.1v Protocol VLAN: V
MAC-based VLAN: V
IP Subnet-based VLAN: V

Trunking:

IEEE 802.3ad LACP: up to 16 ports in a group , max. up to 13 groups
Static Trunk: up to 16 ports in a group , max. up to 13 groups

IGMP Snooping (v1/v2/v3): V
Loop Detection: V

L3 Features:

IP Host Table: V
IPv4/v6 Static Routing: V
Static ARP: V
DHCP Server: V

QoS Features

Hardware Queues: 8
Class Of Service:

Port Based: V
802.1p: V
CoS: V
DSCP: V
TCP/UDP (IPv4/IPv6): V

Rate Limiting:

Ingress V
Egress V

Priority Queue Scheduling:

WRR: V
Strict Priority: V

IPv4 QoS (QCEs): V
IPv6 QoS (QCEs): V

Security:

Port Security (MAC-based): V
IEEE802.1x: V
ACLs:

Source and Destination MAC, VLAN ID or IP Address, Protocol, Port: V
(DSCP) / IP Precedence: V
TCP/ UDP Source and Destination Ports: V
802.1p Priority: V
ICMP Packets: V

IP Source Guard (IP-MAC-Port Binding): V
Storm Control: V
RADIUS Authentication (RFC2138): V
DDoS Prevention: V
Layer 3 Isolation (Allow/Disallow Routing between IP Subnets): V
HTTPs and SSL (Secured Web): V
SSH v1.5/v2.0 (Secured Telnet Session): V
BPDU Guard: V
STP Root Guard: V
DHCP Snooping: V

Management:

SNMP (v1, v2c, v3): V
RMON (1, 2, 3 & 9 groups): V
Software Upgrade: V
Configuration Export/Import: V
DHCP:

Client: V
Option 66: V
Option 67: V

Event/Error Log:

Syslog: V

Management Access Filtering:

SNMP: V
Web: V
Telnet: V

Port Mirroring: V
MLD Snooping: V
LLDP (IEEE802.1AB): V
LLDP-MED: V
CDP: V
NTP/ SNTP (RFC2030): V
TFTP: V

IPv6 Support

Dual IPv6/IPv4 Stack: V
IPv6 Web/SSL: V
IPv6 SNTP (Simple Network Time Protocol): V
IPv6 Telnet Server/SSH: V
IPv6 Ping Trace Route: V
IPv6 TFTP: V
IPv6 RADIUS: V
IPv6 Syslog: V
IPv6 DNS Client: V
IPv6 Protocol-based VLANs: V
IPv6 SNMP: V

PoE Management

ON/OFF Config: V
Alive Checking for PD: V
Power Delay: V
7/24 On/Off Scheduling: V
PoE Function:
Number of PoE Out Ports: 24
PoE Output Power: Per Port 54VDC, Max. 30W
802.3at/af Standard Compatible: V
Over Current Protection: V
Circuit Shorting Protection: V
Total PoE Power Budget: 370W
Power Pin Assignment: 1/2(+), 3/6(-)
PoE PD Auto Detection: V

Environmental Specifications

Operating Temperature: 0°C ~ 50°C (32°F ~ 122°F)
Operating Humidity: 10 ~ 90% RH
Storage Temperature: -20°C ~ 70°C (-4°F ~ 158°F)
Storage Humidity: 10 ~ 90% RH
Mechanical Specifications:

Dimensions: 44 (H) x 442 (W) x 211 (D) mm
Weight: 3.1 kg

Power Source:

AC Input: 100V-240V
Frequency: 50~60 Hz
Power Consumption: 430W

Certifications

Certifications: FCC, LVD, VCCI, C-Tick

Accessories

Optional Accessories:

SFP Transceiver:

SFP-1000-MM85-X5: MMF, 0.5 km, 0°C ~ 70°C
SFP-1000-MM13-02: MMF, 2 km, 0°C ~ 70°C
SFP-1000-SM13-10: SMF, 10 km, 0°C ~ 70°
SFP-1000-SM13-40: SMF, 40 km, 0°C ~ 70°C
